Pinos Extratores DIN 1530D (cabeça chanfrada)
Material: Aço Prata tungstenado (WS)
Dureza: 60 - 2 HRC
Cabeça: 45+- 5 HRC
Haste mais grossa em baixo da cabeça devido ao forjamento.
Desenho Técnico
Tabela
D1 g6 | K +0,2 | D2 -0,05 | L+2mm | |||
|---|---|---|---|---|---|---|
100 | 125 | 160 | 200 | |||
1,0 | 0,5 | 1,8 | PED01.0100 | PED01.0125 | PED01.0160 | PED01.0200 |
1,1 | 0,5 | 1,8 | PED01.1100 | PED01.1125 | PED01.1160 | PED01.1200 |
1,2 | 0,5 | 2,0 | PED01.2100 | PED01.2125 | PED01.2160 | PED01.2200 |
1,3 | 0,5 | 2,0 | PED01.3100 | PED01.3125 | PED01.3125 | PED01.3200 |
1,4 | 0,5 | 2,2 | PED01.4100 | PED01.4125 | PED01.4125 | PED01.4200 |
1,5 | 0,5 | 2,2 | PED01.5100 | PED01.5125 | PED01.5160 | PED01.5200 |
1,6 | 0,5 | 2,5 | PED01.6100 | PED01.6125 | PED01.6160 | PED01.6200 |
1,7 | 0,5 | 2,5 | PED01.7100 | PED01.7125 | PED01.7160 | PED01.7200 |
1,8 | 0,5 | 2,8 | PED01.8100 | PED01.8125 | PED01.8160 | PED01.8200 |
1,9 | 0,5 | 2,8 | PED01.9100 | PED01.9125 | PED01.9160 | PED01.9200 |
2,0 | 0,5 | 3,0 | PED02.0100 | PED02.0125 | PED02.0160 | PED02.0200 |
2,1 | 0,5 | 3,2 | PED02.1100 | PED02.1125 | PED02.1160 | PED02.1200 |
2,2 | 0,5 | 3,2 | PED02.2100 | PED02.2125 | PED02.2160 | PED02.2200 |
2,3 | 0,5 | 3,5 | PED02.3100 | PED02.3125 | PED02.3160 | PED02.3200 |
2,4 | 0,5 | 3,5 | PED02.4100 | PED02.4125 | PED02.4160 | PED02.4200 |
2,5 | 0,5 | 3,5 | PED02.5100 | PED02.5125 | PED02.5160 | PED02.5200 |
2,6 | 0,5 | 4,0 | PED02.6100 | PED02.6125 | PED02.6160 | PED02.6200 |
2,7 | 0,5 | 4,0 | PED02.7100 | PED02.7125 | PED02.7160 | PED02.7200 |
2,8 | 0,5 | 4,0 | PED02.8100 | PED02.8125 | PED02.8160 | PED02.8200 |
2,9 | 0,5 | 4,0 | PED02.9100 | PED02.9125 | PED02.9160 | PED02.9200 |
3,0 | 0,5 | 4,5 | PED03.0100 | PED03.0125 | PED03.0160 | PED03.0200 |
3,1 | 0,5 | 4,5 | PED03.1100 | PED03.1125 | PED03.1160 | PED03.1200 |
3,2 | 0,5 | 4,5 | PED03.2100 | PED03.2125 | PED03.2160 | PED03.2200 |
3,3 | 0,5 | 4,5 | PED03.3100 | PED03.3125 | PED03.3160 | PED03.3200 |
3,4 | 0,5 | 4,5 | PED03.4100 | PED03.4125 | PED03.4160 | PED03.4200 |
3,5 | 0,5 | 5,0 | PED03.5100 | PED03.5125 | PED03.5160 | PED03.5200 |
3,6 | 0,5 | 5,0 | PED03,.6100 | PED03.6125 | PED03.6160 | PED03.6200 |
3,7 | 0,5 | 5,0 | PED03.7100 | PED03.7125 | PED03.7160 | PED03.7200 |
3,8 | 0,5 | 5,0 | PED03.8100 | PED03.8125 | PED03.8160 | PED03.8200 |
3,9 | 0,5 | 5,0 | PED03.9100 | PED03.9125 | PED03.9160 | PED03.9200 |
4,0 | 0,5 | 5,5 | PED04.0100 | PED04.0125 | PED04.0160 | PED04.0200 |
4,1 | 0,5 | 5,5 | PED04.1100 | PED04.1125 | PED04.1160 | PED04.1200 |
4,2 | 0,5 | 5,5 | PED04.2100 | PED04.2125 | PED04.2160 | PED04.2200 |
4,3 | 0,5 | 5,5 | PED04.3100 | PED04.3125 | PED04.3160 | PED04.3200 |
4,4 | 0,5 | 5,5 | PED04.4100 | PED04.4125 | PED04.4160 | PED04.4200 |
4,5 | 0,5 | 6,0 | PED04.5100 | PED04.5125 | PED04.5160 | PED04.5200 |
4,6 | 0,5 | 6,0 | PED04.6100 | PED04.6125 | PED04.6160 | PED04.6200 |
4,7 | 0,5 | 6,0 | PED04.7100 | PED04.7125 | PED04.7160 | PED04.7200 |
4,8 | 0,5 | 6,0 | PED04.8100 | PED04.8125 | PED04.8160 | PED04.8200 |
4,9 | 0,5 | 6,0 | PED04.9100 | PED04.9125 | PED04.9160 | PED04.9200 |
5,0 | 0,5 | 6,5 | PED05.0100 | PED05.0125 | PED05.0160 | PED05.0200 |
5,1 | 0,5 | 6,5 | PED05.1100 | PED05.1125 | PED05.1160 | PED05.1200 |
5,2 | 0,5 | 6,5 | PED05.2100 | PED05.2125 | PED05.2160 | PED05.2200 |
5,3 | 0,5 | 6,5 | PED05.3100 | PED05.3125 | PED05.3160 | PED05.3200 |
5,4 | 0,5 | 6,5 | PED05.4100 | PED05.4125 | PED05.4160 | PED05.4200 |
5,5 | 0,5 | 7,0 | PED05.5100 | PED05.5125 | PED05.5160 | PED05.5200 |
5,6 | 0,5 | 7,0 | PED05.6100 | PED05.6125 | PED05.6160 | PED05.6200 |
5,7 | 0,5 | 7,0 | PED05.7100 | PED05.7125 | PED05.7160 | PED05.7200 |
5,8 | 0,5 | 7,0 | PED05.8100 | PED05.8125 | PED05.8160 | PED05.8200 |
5,9 | 0,5 | 7,0 | PED05.9100 | PED05.9125 | PED05.9160 | PED05.9200 |
6,0 | 0,5 | 8,0 | PED06.0100 | PED06.0125 | PED06.0160 | PED06.0200 |
6,1 | 0,5 | 8,0 | PED06.1100 | PED06.1125 | PED06.1160 | PRD06.1200 |
6,2 | 0,5 | 8,0 | PED06.2100 | PED06.2125 | PED06.2160 | PED06.2200 |
6,3 | 0,5 | 8,0 | PED06.3100 | PED06.3125 | PED06.3160 | PED06.3200 |
6,4 | 0,5 | 8,0 | PED06.4100 | PED06.4125 | PED06.4160 | PED06.4200 |
6,5 | 0,5 | 9,0 | PED06.5100 | PED06.5125 | PED06.5160 | PED06.5200 |
7,0 | 1,0 | 9,0 | PED07.0100 | PED07.0125 | PED07.0160 | PED07.0200 |
7,5 | 1,0 | 10 | PED07.5100 | PED07.5125 | PED07.5160 | PED07.5200 |
8,0 | 1,0 | 10 | PED08.0100 | PED08.0125 | PED08.0160 | PED08.0200 |
8,5 | 1,0 | 11 | PED08.5100 | PED08.5125 | PED08.5160 | PED08.5200 |
9,0 | 1,0 | 11 | PED09.0100 | PED09.0125 | PED09.0160 | PED09.0200 |
9,5 | 1,0 | 12 | PED09.5100 | PED09.5125 | PED09.5160 | PED09.5200 |
10 | 1,0 | 12 | PED10.0100 | PED10.0125 | PED10.0160 | PED10.0200 |
11 | 1,0 | 13 | PED11.0100 | PED11.0125 | PED11.0160 | PED11.0200 |
12 | 1,0 | 14 | PED12.0100 | PED12.0125 | PED12.0160 | PED12.0200 |
13 | 1,0 | 15 | PED13.0100 | PED13.0125 | PED13.0160 | PED13.0200 |
14 | 1,0 | 16 | PED14.0100 | PED14.0125 | PED14.0160 | PED14.0200 |
